GDM101 series molded case circuit breaker is suitable for AC 50Hz rated working voltage 380V and below, its rated current ranges from 16A to 600A. It is generally used in power distribution to distribute electrical energy and protect lines and power equipment from overload and short circuit. The transparent molded case circuit breaker has a visual switch state with visible breakpoints and can also be used as an isolating switch. The circuit breaker can also be equipped with auxiliary accessories such as contacts and shunt release.

Comply with the IEC60947-2、GB/T 14048.2 Standard

Frame Size：100、160、250、400、600

Current Grade：15-100A、63-160、100-250A、200-400、200-600A

Shor Circuit Breaking Capacity：Icu=7、7、18、10、25 kA

Poles：3
